Non-contact measurement and 3-in-1 Supply Chain Solution

Save time with ScanCube's 3-in-1 solution
Product Photo + Non-Contact Measurement + Weighing

This 3-in-1 solution enables supply chain operators to obtain the dimensions and weight of their products, through photography. Thanks to EasyScanCube (ESC) software and measurement sensors, you can obtain the data you need to feed your PIM in just a few clicks.

The advantages of the 3-in-1 solution with non-contact measurement.

mesure sans contact-pictogramme produits mesurés, pesés-scancube

Photographed, measured and weighed products

The 3-in-1 solution enables supply chain operators to quickly obtain visuals of their products. Each product is supplied with its weight and dimensions.
mesure sans contact-pictogramme visuels de qualité-scancube

High-quality visuals

Your photos are taken in HD and in large quantities, in the format of your choice. No knowledge of photography is necessary, as the EasyScanCube software is intuitive.
mesure sans contact-pictogramme réduction des coûts-scancube

Cost reduction

The 3-in-1 solution will cut your costs by 50% and help you avoid logistical errors.
Request a demo

What is the role of non-contact measurement in the 3-in-1 solution?

mesure sans contact-pictogramme gain de temps-scancube

Time saving

With non-contact measurement (NCM), you can optimise your time automatically by measuring the dimensions of your parts. Including their weight.
pictogramme automatisation-scancube


Depending on your specifications, you can create a personalised shooting scenario that includes three-dimensional metrology. The measurement system will then be automatically integrated into your photo and video shoots.
mesure sans contact-pictogramme sauvegarde des données-scancube

Data backup

With our new technology, contactless data is saved in a software file. When you do future shoots, the dimensions of future products will be saved in the same file.
pictogramme rapidité-scancube


In less than 5 minutes, your visuals are created and the geometric measurements recorded. All you have to do is export them.

ScanCube non-contact measurement technology.

The 3-in-1 solution retains the main functions of our EasyScanCube software, which it feeds into the measurement and weighing system.

Once your products have been placed on the weighing platform, our Supply Chain technology enables them to be measured without physical contact.

ScanCube image analysis covers several types of measurement
Diameter measurement;
Thickness measurement;
Radius measurement;
Angle measurement;
Distance measurement.
By scanning the product from all angles, the photographic rendering provides the geometric dimensions of the item being measured. Length, width and depth are expressed in cm. At the same time, the weight is calculated and expressed in kilograms.

All the dimensions produced by Supply Chain technology help to limit measurement errors.

The displacement sensors of the backlit turntable enable all the dimensions of your parts to be calculated to the nearest micrometre. Measurement system errors are virtually non-existent.

How does it work?

The 3-in-1 solution is based on NCM technology. It allows you to obtain three-dimensional values once your product has been shot and scanned.

Measurement data in cm is immediately stored in a file and easily exported.

Non-contact measurement is ideal for the industrial and logistics sectors; image analysis means you can obtain all the precise measurements of your product in an instant.

Simple process

Place your product in the beam of the backlit weighing tray. Activate the laser beam to centre it;
With just one click, you can create your own personalised shooting scenario;
In just a few clicks, you can get a high-quality visual or 360° animation of your product.
Request a demo

Non-contact measurement

The 3-in-1 solution lets you take high-precision measurements of your product.

Place your product in the beam of the weighing tray. The laser sensors will help you centre it.

The software takes several shots of your product.

Thanks to the laser beam and the sensors in the measuring range, you can carry out an image analysis of your product.

Finally, the MSC is carried out. The various types of measurement (angle, radius, diameter, thickness, etc.) are calculated by the three-dimensional measurement system.

This will give you the geometric data for your product (length, width, depth).
Request a quote

Product weight

Your item is weighed at the same time as your rapid measurement. The weighing plate's photogrammetry technology enables the weighing to be linked to the dimensions of the product.

N.B.: The measurement system can be separated from the weighing system, depending on the specifications required.
Ask our experts for more information

The uses of ScanCube contactless measurement.

mesure sans contact-pictogramme colis prêts en un rien de temps-scancube

Parcels prepared in no time

With non-contact measurement, you can plan the packing and packaging of your future products.
mesure sans contact-pictogramme gestion logistique simplifiée-scancube

Simplified logistics management

Improve efficiency: your teams will be able to forecast shop occupancy rates and predict store organisation, thanks to the accuracy of the measurements.
mesure sans contact-pictogramme livraison anticipée-scancube

Early delivery

Thanks to photogrammetry technology, you'll be able to know the packaging of the measured parts so you can anticipate the delivery of your products.
mesure sans contact-pictogramme amélioration service client-scancube

Improved customer service

Your teams will have all the necessary product information. You can be more efficient and meet your customers' needs.

ScanCube contactless measurement users.

Which sectors are the most affected?

The NCM will benefit sectors in need of a rapid measurement system. This system will be particularly useful for the following sectors:
Mass distribution
Technical support
Machinery and equipment

What professions are involved in contactless measurement?

The NCM benefits jobs in the sectors mentioned above. More generally, all jobs linked to the supply chain are concerned.

Here are just a few examples of jobs that can benefit from contactless measurement:
Transport buyer
Assistant import/export manager
Logistics assistant/technician
Engineering and deployment project manager
Methods and Organisation Project Manager
Logistics Platform Manager
Customer Service Director
Supply Chain Director
Transport Manager
Logistics Methods Engineer
Branch Manager
Site manager
Purchasing Manager
Operations manager
Transport Operations Manager
Business Unit Manager
Contract Manager
Head of Sales Administration
Logistics Coordinator
Logistics Director
Logistics Manager
Material Handler
Methods Manager
Order Picker
Planning Manager
S&OP Manager
Sales Forecast Manager
Sales Manager
Supply Chain IS Project Manager
Supply Chain Manager
Supply Manager
Transport Manager
Warehouse Operator

ScanCube's expertise.

Non-contact measurement
360° animations
trimming, hyperfocus

Frequently asked questions about contactless measurement

It refers to a dimensional measurement method that does not require direct physical contact with the object being measured. It uses special sensors and instruments to obtain accurate data without disturbing the object.
NCMs offer a number of advantages, including high accuracy, the ability to measure fragile or sensitive objects, ease of use and the ability to measure at a distance without disturbing the object.
The measuring instruments used for NCM include sensors, probes, infrared thermometers, scanners, profile projectors, thermal cameras, displacement sensors, spectrometers, scales and interferometers.
Non-contact measurements are widely used in many fields, including industry, metrology, aeronautics, the automotive industry, scientific research, medicine, architecture and the environment.
Non-contact sensors use different technologies such as infrared, laser triangulation, optical measurement and magnetic induction to detect and measure variables such as temperature, distance, position and humidity, without touching the object.

NCM is important for optical measurement because of its ability to preserve object integrity, provide fast, accurate and non-invasive measurements, and adapt to complex surfaces.
They can be highly accurate, depending on the instruments used and the measurement method. Some instruments are capable of measuring to within a few microns.
It offers a number of advantages over traditional measurement methods, such as greater accuracy, fewer errors due to physical contact, the ability to measure objects that are difficult to access, and faster measurements.
The 2 are closely linked in the field of vision engineering. Non-contact measurement uses optical techniques to capture and analyse the dimensions of objects, while machine vision uses cameras and software to inspect, measure and control parts and manufacturing processes.
Choosing the right instrument depends on the specific needs of your application. It is important to consider the variables to be measured, the measurement range, the accuracy required and the instrument's specific features.
Although they offer many advantages, they can also have certain limitations. For example, some surfaces may not be suitable, and environmental interference may affect measurements. It is important to understand the limitations of each measurement method.
Factors influencing its quality include sensor resolution, calibration accuracy, adequate lighting, system stability, the nature of the surface being measured and bandwidth for real-time measurements.
The profile projector can be considered as a type of measuring device used to carry out non-contact measurements. It uses optical principles to project the image of an object onto a screen or profile sensor. The profile sensor is an essential component of the profile projector, responsible for capturing information about the surface of the object.

The profile projector enables dimensional and geometric measurements to be made with a high degree of accuracy without having to come into physical contact with the object being measured. It uses a beam of light to project an enlarged image of the object onto a screen, where the object's contours and features can be observed and measured. Profile sensors record this information and transform it into usable digital data.

By combining the profile projector with a profile sensor, it is possible to measure dimensions, angles, shapes and other features without directly touching the object. This non-contact measurement method is commonly used in metrology, manufacturing and quality control, where accurate and repeatable measurements are required.

The profile projector and profile sensor are key components of non-contact measuring equipment, enabling dimensional and geometric data to be obtained with high precision, while preserving the integrity of the object being measured.
Deformation measurement is a technique used to evaluate changes in the shape or size of an object when it is subjected to external forces, stresses or loads. It is used to quantify variations in the size or shape of a material or structure under the effect of mechanical stress.

Various techniques and instruments can be used to measure deformation. Among them, visio machines (or vision machines) and displacement sensors play an important role.

Machine vision systems use cameras and image processing algorithms to capture and analyse the deformations of an object. They can accurately measure variations in the shape or size of a part by analysing the images obtained.
1.  Product quality control: Your lightbox can be used to capture high-resolution images of products manufactured in-house. This enables you to carry out precise visual checks and detect defects, imperfections or variations in quality.

2. Documentation and archiving: Photos taken in your lightbox can be used to document and archive manufactured products. They provide a visual reference for tracking production progress, comparing different product versions and providing evidence in the event of disputes or customer complaints.

3. Catalogues and advertising: High-quality photos taken in your lightbox can be used to create catalogues, brochures and advertising materials. They showcase your company's products in an attractive and professional way, making promotion and marketing easier.

4. E-commerce and online marketing: Product images from your lightbox are essential for businesses that sell online. They enable products to be presented in a clear, detailed and attractive way, boosting online sales and improving the user experience.

5. Design and prototyping: Your photo shooting solution can also be used in the product design and prototyping process. High-quality photos can be used to visualise ideas, evaluate designs, make adjustments and share information with design and engineering teams.

6. Internal and external communication: The images captured in your lightbox can be used for internal communication within the company, for example to present products at meetings, training sessions or in reports. They can also be used to communicate with customers, partners and suppliers, providing clear, professional visuals of products.
There are various types of non-contact measuring machine used in different fields and applications. Here are some of the most common types:

1. Vision measuring machines: These machines use high-resolution cameras to capture images of the objects to be measured. They are often equipped with image analysis software to extract information such as dimensions, contours and surface defects.

2. Laser scanning measuring machine: These measuring machines use a laser beam to scan the surface of an object and measure its topography in 3D. They provide precise data on the shape, dimensions and defects of the object.

3. Optical scanning measuring machines: These machines use a technology that projects patterns or fringes of light onto the object to be measured. By analysing the deformations of the projected patterns, they reconstruct the 3D geometry of the object.

4. Interferometric measuring machine: This type of measuring device uses the principle of optical interference to accurately measure variations in the height or distance of a surface. It is often used for applications requiring high accuracy, such as measuring roughness or thickness.

5. Tomography measuring machine: These machines use tomography techniques, such as optical coherence tomography (OCT), to create cross-sectional images of the inside of an object. They are commonly used in the medical field, particularly for ocular imaging.

6. Ultrasonic measuring machine: These machines use ultrasonic waves to measure dimensions, thicknesses and defects in materials. They are often used in industry for non-destructive testing of parts.

7. Infrared thermography measuring machine: These machines use thermal cameras to measure variations in the temperature of an object. They are useful for detecting hot spots, heating faults and insulation problems.

8. Profilometry measuring machine: These machines use optical sensors to measure the surface profiles of an object. They can measure roughness, dimensions and contours with great precision.
Photographic non-contact measurement solutions use optical measurement principles to assess the dimensions of parts. Here are some of the types of measuring equipment commonly used in these solutions:

1. Machine vision systems: These devices use cameras and image processing software to capture and analyse the dimensions of parts. The images are processed to extract information such as object lengths, angles and contours.

2. 3D scanners: These devices create accurate three-dimensional models of parts by capturing clouds of points from multiple viewing angles. Processing software then converts these point clouds into 3D models, which can be accurately measured.

3. Optical profilometers: These devices use structured light projection techniques to measure the profiles and dimensions of part surfaces. They project a series of fringes or patterns onto the surface of the part, then analyse the deformations of these patterns to deduce the dimensions.

4. Interferometers: These instruments measure variations in the wavelength of light reflected or transmitted by a surface. They are capable of detecting extremely precise variations in dimensions, particularly in applications requiring high precision, such as optics or the semiconductor and electronic component industries.

5. Photogrammetry systems: These use triangulation techniques, analysing images captured from several cameras to reconstruct the 3D geometry of parts. These systems are particularly useful for measuring large parts or moving objects.
